Medium Excavators
SK260LC-10
- Standard factory fitted quick hitch piping and tilt circuit piping.
- 2YR/3,000HR Full Machine Warranty and 4YR/6,000HR Major Component Extended Warranty.
The Generation 10 SK260LC has advanced technology that improves hydraulic efficiency, with lower fuel consumption by 17% in H-mode, 14% in S-mode and 23% in Eco-mode than previous models. Takes 38% less effort to work the operation lever, which reduces fatigue over long hours of operation.
With nimble movement and ample digging power, this excavator promises to improve productivity, and has superior digging force, top class travelling force and working ranges. Rugged durability that ensures long-term machine value and includes Kobelco Geoscan Excavator Remote Monitoring System.
Specifications
Transport Dimensions
Length, Width & Height
10.21 x 3.19 x 3.09 m
Operating Weight
25,700 kg
Refilling Capacities
Fuel Tank
403 L
Hydraulic Oil Tank
165 (273) L
Working Range
Max. Digging Depth
7.0 m
Max. Digging Reach
10.31 m
Engine
Rated Power Output
137 kW
Rated Torque
639 Nm
Breakout Force
Bucket Digging Force
187 kN
Arm Crowding Force
131 kN
Hydraulic System
Max. Pump Flow
2 x 245 + 21 L/min
Standard Auxiliary
N&B + Tilt Piping
