Large Excavators
SK530LC-11
- Tier IV Final Compliant Engine.
- New 345 kW engine delivers exceptional excavation performance.
- Kobelco’s GEOSCAN telematics system is also provided free of charge for 5 years, allowing remote access to a comprehensive set of machine operational and maintenance data from any web enabled device.
- Includes Kobelco’s Extended Major Component Warranty of 4 years/6,000 hours!
Designed for the most extreme working conditions, this 53-tonne excavator is engineered to deliver exceptional performance, productivity and relaibility.
Powered by a 345 kW high output engine that is Tier IV compliant, it combines impressive digging force, heavy lifting and smooth hydraulic performance to maximise productivity.
Designed with both operator comfort and uptime in mind, the SK530LC-11 features a spacious, premium cabin with ergonomic controls, an air suspension seat, a large 10-inch colour monitor and an advanced multi-camera safety system for excellent visibility. Kobelco’s Geoscan Excavator Remote Monitoring System provides added peace of mind by enabling remote machine monitoring and helping operators and fleet managers maximise uptime.
Specifications
Transport Dimensions
Length, Width & Height
12.16 x 3.58 x 3.67 m
Operating Weight
53,100 kg
Refilling Capacities
Fuel Tank
720 L
Hydraulic Oil Tank
370 (803) L
Working Range
Max. Digging Depth
7.77 m
Max. Digging Reach
12.07 m
Engine
Rated Power Output
345 kW
Rated Torque
1,980 Nm
Breakout Force
Bucket Digging Force
321 kN
Arm Crowding Force
242 kN
Hydraulic System
Max. Pump Flow
2 x 370 L/min + 58.5 L/min + 27 L/min
Standard Auxiliary
N&B + Tilt Piping
Excavator Brochure
Compare Excavator
